JSM1
GaeaCycle
Features:
* 7000w powerful motor, top speed 115km/h
* 280km long range with 72v 115ah lighium battery
* EEC certificated, L3e COC certificate.
* New energy charging port can be installed
| Dimension (L×W×H) | 1950*790*1075(mm) |
| Brake system (front/rear) | F/R Dual channel ABS anti-lock disc brake system |
| Max Speed (km/h) | 110-115Km/h |
| Range per charge (km) | 280KM (Keep Driving at 35Km/h). 170KM (WMTC TEST) |
| Total weight (kg) | 103kgs(without battery) |
| Loading Weight | 300kg |
| Motor rating power (W) | 7000W |
| Battery type | 72V115AH Lithum Battery (full charging 86V). Canbus Communication |
| Meter | 5 Inch TFT Colorful display. Canbus Communication. Bluetooth. WIFI. GPS Mobile Phone connect. Caller ID Display.Charging animation effect |
| Removable Battery | No |
| Recharge cycles (times) | 1000 times |
| Input voltage | 110V/220V 50-60Hz |
| Charger | 72V25A Canbus Communication / IP67 Waterproof（build in scooter body） |
| Charger time | 4.6-5 Hours |
| Tyre size | F:110/70-13 Semi Hot Melt Tire / Kenda R:130/60-13 Semi Hot Melt Tire / Kenda |
| Controller | Programable 72V150A Maxed 270A. 30 Mos Tube. Canbus Communication. |
| Climbing slope | 25° |
| Packing size | 1900*680*1250mm |
| QTY | 18pcs/20GP(9 pcs/SKD) . 36pcs/40HQ(CBU) |
